Shorty DOC SBR 5.56 QUAD

$2,000.00

The Shorty is 5.8 LBS of pure flexibility. Short enough for those tight spaces and long enough to reach out to 300 yards if needed. Loaded with Picatinny so no messing with attachments for attachments.

The Handguard

  • 10 inches made from 6061 T6 Aluminum
  • Picatinny at 3,6,9 o’clock for versatile mounting options.
  • Full length picatinny on top rail.
  • Front and rear a QD points on both sides
  • Retention system and anti rotational tabs that prevents movement of handguard during use.

The Barrel

  • 10.3 inch 1:7 Twist Hanson profile.
  • Carbine length DI gas system for smoother cycling and pinned non adjustable gas block.
  • CrMoV with QPQ finish eliminating the need for chrome lining.
  • HP and MPI tested.
  • A2 Flash hider..

In stock items are built and ready to ship.

(Expect 12 weeks for shipping on any backordered items) We are trying hard to get this time down so thank you for your business and patience.

Available on backorder

Category: SKU: 10004

Description

THE BCG

  • The beating heart of our rifles and there are no denying it has a strong heart.
  • Precision ground inside and out for a near frictionless surface ensuring long term reliably.
  • ArmorLube coating (advanced DLC and MILSPEC)
  • Bolt is machined from 9310 steel and properly heat treated, MPI and shot peened for superior strength and durability.
  • 100% American made and full auto capable.

BILLET LOWER GEN 2

  • Lower receiver is billeted from 7075 T6 aluminum with a solid piece trigger guard and cut out shelf.
  • Right side bolt release
  • Flared mag well for faster reloads under stress.
  • Enhanced buffer tube features
    • Position drain holes to that easily removes water in maritime environments and prevents build up of gas and creating smoother cycling of BCG.
    • Carrier support extension that guides BCG into the extension prohibiting carrier tilt and excessive carrier wear while holding the buffer pin in place and making backing out under recoil impossible.
  • MD H1 buffer and stainless steel cryo treated flat wire buffer spring that eliminates “twang” noise and increasing forward pressure which greatly increases reliability.
  • Geissele 2 stage SSA trigger

BILLETED UPPER

  • Billeted upper receiver from 7075- T6 aluminum to extremely tight tolerances to ensure proper cycling and a perfectly flat surface for flush fit for the barrel.
  • The barrel and the upper receiver are thermal fit to lock the barrel in for an extremely tight connection. This increases the rifles durability and gives it bolt like accuracy.

Additional information

BCG

Precision ground, Heat treated, Shot peened, MPI
BCG Coating

ArmorLube advanced DLC – MILSPEC
Billet Upper

Billet 7075- T6 aluminum
Billet Lower

Billet 7075- T6 aluminum
The Barrel

Performance CrMoV Hanson profile
Barrel Length

10.3''
Barrel Twist

1:7
Gas System

Carbine DI
Hand Guard

6061 T6 Aluminum Quad Rail
Caliber

5.56/.223
Rail Mounting System

Picatinny
Muzzle Threads

1/2×28
Weight

5.8 LBS
Length

Short
Magazine

Standard AR 5.56 mag
Case

Bull Dog DELUXE 36″ SINGLE TACTICAL RIFLE
Trigger

Geissele SSA two stage
Safety Selector

Radian Ambidextrous
Charging Handle

MD Marked Radian Raptor Ambi
Coating

E series Cerakote on top of Type 3 Hardcoat Anodized
Buffer Weight

H1
Buffer Spring

Proprietary Flat Wire
